Omron TM5 Regular Payload Series

Regular Payload Series-Hardware Installation Manual TM5 Series 65
6.4.4 Connect the Robot and Control Box
Connect the power cable from the control box to the robot, and then connect the power cable from AC
power to the control box to boot up the controller.
WARNING:
1. Ensure that all cables are correctly connected before the control box is energized. Always
use genuine power cables correctly.
2. When the robot is turned on, do not disconnect cables of the robot. When cables of the
robot are not connected to the connection interface, do not turn on the robot.
3. Do not extend or modify the original cables of the robot.
