Omron TM5 Regular Payload Series User Manual

Regular Payload Series-Hardware Installation Manual TM5 Series 41
5.3.2 Power Connector
1. During boot, the control box will check for an external 24V input. If none is found, then it will switch to
the internal 24V supply.
2. The control box itself offers a 24V1.5A output (24_EX). If the 24V load exceeds 1.5A, it enters Safe
Mode and disables the 24V output.
3. EX24V provides an external 24V input port. If the load exceeds 1.5A an external power supply can be
used instead. The load on EX24V must not exceed 3.5A.
External
Power Supply
(24V)
24V
■
0V
■

Omron TM5 Regular Payload Series Specifications

General

Payload	5 kg
Reach	900 mm
Number of Axes	6
Repeatability	±0.05 mm
IP Rating	IP54
Degrees of Freedom	6
Mounting	Floor, Ceiling, Wall
Power Supply	200-240 VAC, 50/60 Hz
Controller	Built-in
