Omron TM5 Regular Payload Series

Regular Payload Series-Hardware Installation Manual TM5 Series 52
TM5M-700 / TM5M-900 Series
External Power Supply Remote Control
DC IN Power
DC Power Switch
DC IN for External Power Supply
USB 3.0*2
COM1
Robot Cable Adapter
USB 2.0 *4
HDMI
LAN for GigE Camera*2
EtherCAT
Line-out
Air Filter Screw
Power Remote ON/OFF
COM2
COM3
LAN
Mic-in
I/O Interface
PE
TM5M-700 SEMI / TM5M-900 SEMI Series
External Power Supply Remote Control
DC IN Power
DC Power Switch
DC IN for External Power Supply
USB 3.0*2
COM1
Robot Cable Adapter
USB 2.0 *4
HDMI
LAN for GigE Camera*2
EtherCAT
Line-out
Air Filter Screw
Power Remote ON/OFF
COM2
COM3
LAN
Mic-in
I/O Interface
PE
EMO
