Step-by-step configuration Crocus CNV
56 User manual
5.2.1 The load default configuration DIP switch
The location of the load default configuration DIP switch is:
DIP switch name DS5 no. Setting Function
on
Normal operation.
load default
configuration
1 (CV-A)
2 (CV-B & TT)
off Load default configuration.
To load the default configuration using the appropriate DIP switch, proceed as follows:
Step Action
1 In case of a …
• TT, open the housing as described in Section 3.1.4 - Changing DIP switch and strap
settings of the Table Top.
• CV, remove the card from the CN4 card nest as described in Section 3.2.5 -
Changing DIP switch and strap settings of the Card Version.
2 In case of a …
• TT, set DIP switch bank DS5 position 2 to off. To locate this DIP switch bank, refer to
Section 3.1.1 - Location of the DIP switches and straps on the Table Top.
• CV, set DIP switch bank DS5 position 1 (for converter A) and / or 2 (for converter B)
to off. To locate this DIP switch bank, refer to Section 3.2.1 - Location of the DIP
switches on the Card Version.
3 In case of a …
• TT, close the housing without fastening the screws.
• CV, insert the card in the CN4 card nest without fastening the screws.
⇒ The Crocus CNV reboots and loads the default configuration.
4 Activate the loaded default configuration:
1. Open a TMA session on the Crocus CNV (refer to Section 4.2 - Connecting to a
Crocus CNV with TMA).
(✱)
2. Execute the Activate Configuration command.
(✱)
If you are performing this load default configuration procedure because you
accidentally made a configuration error, you have the possibility to retrieve this
erroneous configuration before executing the Activate Configuration command. In that case
you do not have to reconfigure the complete device again, but you only have to correct
the error in question. Retrieve the erroneous configuration by executing the Load saved
configuration command.
5 Reset the corresponding DIP switch to on. Refer to step 2.
6 In case of a …
• TT, close the housing.
• CV, insert the card in the CN4 card nest.
⇒ The Crocus CNV reboots in normal operation mode.
