Crocus CNV Step-by-step configuration
User manual 57
5.2.2 The Load Default Configuration action in TMA
The location of the Load Default Configuration action in the Crocus CNV containment tree is:
crocusIfConv<2m/Nx64><Tt/Cv>/Load Default Configuration
To load the default configuration, proceed as follows:
Step Action
1
In the TMA window, select the top object crocusIfConv<2m/Nx64><Tt/Cv> and the group
Configuration.
2
In the action window of TMA, click the left mouse button on Load Default Configuration so
that this action is selected.
3 Press the right mouse button and select Execute.
4 To see the default configuration, press the Retrieve all attributes from device button
.
5
In the action window of TMA, click the left mouse button on Activate Configuration so that
this action is selected.
6 Press the right mouse button and select Execute.
