Step-by-step configuration Crocus CNV
68 User manual
5.5.1 Configuring the RTS control (RS530, V35, V36)
crocusIfConv<2m/Nx64><Tt/Cv>/<dteInterface>/rtsControl default: external
Use the rtsControl attribute to define which device will activate the RTS signal.
Normal operation requires the RTS signal (circuit 105) to be active before the Crocus CNV activates its
data transfer state, as indicated by the CTS signal (circuit 106). Therefore, make sure the RTS signal is
activated either by the application or by the Crocus CNV.
If RTS control is
set to …
the RTS signal is
activated by …
Use this setting in case …
external the application. the application has to be in command of the RTS signal.
internal the Crocus CNV. the application is not able to activate the RTS signal.
