WorkBee CNC Limit Switches & Wire Routing 27
A. Attach the Limit-Switch that was inserted in Section 2.1.5 to a Limit-Switch-Plate
using 2 x Plastite-Screw-M3-8mms, the Plastite-Screw-M3-8mms will self thread into
the Limit-Switch. Make sure the Limit-Switch is orientated as the Y-Axis-Limit-Switch-
Assembly above. Finally attach a M5-Low-Profile-8mm bolt, and on the end slightly
thread a M5-Drop-In-Tee-Nut.
B. Repeat Step A for the last Limit-Switch, this one has not been inserted anywhere yet.
Note the different orientation as seen in the X-Axis-Limit-Switch-Assembly above.
C. Attach the Y-Axis-Limit-Switch-Assembly to the left hand Y-Axis C-Beam extrusion (if
looking from the front). It should be attached to the inner slot on the far end of the C-
Beam extrusion. The distance between the Limit-Switch-Plate and the end of the
extrusion should be 13mm.
D. Attach the X-Axis-Limit-Switch-Assembly to the back side of the X-Axis C-Beam extru-
sion. It should be attached to the top slot on the far left side (if looking from the
back). The distance between the Limit-Switch-Plate and the end of the extrusion
should be 10mm.
