WorkBee CNC CNC xPro Assembly 41
A. Insert 4 x M5-Low-Profile-50mm bolts through each mounting hole on the CNC-xPro-
Mount.
B. On to each M5-Low-Profile-50mm bolt slide an Aluminium-Onehalf-Inch and a Slot-
Washer. The rounded face of the Slot-Washer should be flush against the Aluminium-
Onehalf-Inch.
C. On to the end of each M5-Low-Profile-50mm bolt, slightly thread a M5-Drop-In-Tee-
Nut.
D. Bring the CNC-xPro-Assembly to the back of the WorkBee X-Gantry, and align the M5-
Low-Profile-50mm bolt assemblies from Step A/B/C with the backward facing top and
bottom slots on the V-Slot-2040-750mm.
E. With the M5-Low-Profile-50mm bolt assemblies aligned, mate the CNC-xPro-Assembly
with the V-Slot-2040-750mm slots. It should be roughly 10mm from the end of V-
Slot-2040-750mm.
F. Screw each M5-Low-Profile-50mm bolt to engage the M5-Drop-In-Tee-Nut with the
slot. Fully tighten each M5-Low-Profile-50mm bolt.
