PULSAR
2
ESP
Installation and Operating Manual
OPTIKON 2000
Cod. 111007EN Rev.E
8-7
Operation
1) Screw the desired titanium tip into the end of the phaco handpiece, using care
to properly engage the threads. Finger tighten the tip.
2) Carefully advance the ring spanner aperture over the titanium tip (being careful
not to touch the tip) so that the aperture fully engages the circular head at the
base of the tip and positioned against the end of handpiece. Once engaged,
grasp the tip circular head with ring spanner and tighten the tip snugly by
rotating clockwise. Do not over tighten.
3) Remove the ring spanner.
4) If needed gently slide the threaded silicone sleeve over the U/S tip and engage
the sleeve threads. Slowly tighten the sleeve onto the handpiece until the end
of the sleeve leaves the amount of U/S tip exposed as preferred by the surgeon.
Orient the irrigation portholes on the sleeve onto the horizontal plane.
CAUTION:
Use of a tool other than the ring spanner supplied with the system, or
improper use of the ring spanner, may cause damage to the tip and
handpiece. In case of damage, it is possible that titanium particles
detach from tip during surgery.
NOTE:
To disassemble the tip, follow the reverse order from assembly procedure.
5) The handpiece is now ready to accept the irrigation/aspiration tubing from the
PULSAR
2
.
6) Attach the ASPIRATION tube from the I/A tubing set by pushing the end fitting
into the corresponding fitting on the ultrasound handpiece.
7) Attach the IRRIGATION tube from the I/A tubing set by pushing the end fitting
male Luer lock into the corresponding fitting on the ultrasound handpiece.
8) Set I.V. pole height in the Irrigation window so that the BSS bottle is hung 50 to
70 centimetres higher than the patient eye level.
9) Adjust the vacuum level of PULSAR
2
in the Aspiration window according to the
operator needs. In Venturi mode, it is advisable to not exceed the limit of 120
mm/Hg, and to use the slow rise time setting.
