PULSAR
2
ESP
Installation and Operating Manual
OPTIKON 2000
Cod. 111007EN Rev.E
10-3
SYMPTOMS CORRECTIVE ACTION
Irrigation System
No irrigation flowing. a)
Irrigation pinch valve closed. Check by pressing the
footswitch and verify that the irrigation pinch valve
opens and BSS solution is available.
b) Irrigation tube is disconnected from the handpiece.
Connect irrigation tube to the handpiece.
c) Kinked or damaged irrigation tubing. Check for kinks
and straighten. Verify damage and replace if
necessary.
d) Closed clamp on connecting tube to irrigation source.
Release clamp to activate irrigation.
e) Vent valve located on drip chamber closed. Open the
vent valve.
Aspiration System
Poor or missing aspiration. a) I/A tubing set not properly installed. Double check
tubing installation.
b) I/A tubing connectors not properly inserted into the
corresponding connectors on the surgical handpiece.
Insert them properly.
c) I/A tubing set damaged. Exchange for new one.
d) Low "VAC" level. Adjust to slightly higher level.
e) Obstructed tip or handpiece or tubing. Check for
occlusions and clear all debris.
f) Liquid into the air aspiration line. Remove the liquid
with a syringe by sucking from the air aspiration
connector on the side plate or Contact nearest
sales/service office to substitute the liquid-stop
filter.
Err 04 : “I/A Cassette full. Aspiration
halted " message.
a) Tank is full and reserve is exhausted.
Replace I/A cassette.
b) The level sensor (Fig.2, No.6) is wet or dirty. Clean the
sensor with a cotton cloth.
Inconsistency between VAC preset and
VAC actual.
a) Refer to previous paragraph "Poor or missing
Aspiration"
b) If this does not solve the problem then
vacuum/pressure table could be corrupted. Contact
nearest sales/service office to recalibrate the unit.
