Remove Boot Disk Backplane Cables
200 Oracle Database Appliance Service Manual • June 2017
See “Install PCIe Riser in Server Nodes” on page 145.
b.
Install the server node top cover.
See “Installing the Server Node Top Cover” on page 207.
c.
Install the server node into the system.
See “Installing a Server Node Into the System Chassis” on page 208.
d.
Power on the server node.
See “Powering On Oracle Database Appliance Version 1” on page 210.
Servicing the Boot Disk Backplane Cables (FRU)
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 boot disk backplane cables connect the boot disk
backplane to the motherboard.
The boot disk backplane cables are FRUs and can only be replaced by an Oracle-qualified
service technician.
The following topics are covered in this section:
■
“Remove Boot Disk Backplane Cables” on page 200
■
“Install Boot Disk Backplane Cables” on page 201
Remove Boot Disk Backplane Cables
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the boot disk backplane cables from Oracle Database
Appliance Version 1.
1.
Prepare the server node for service.
