Oracle Quad Port 10GBase-T - Adapter Overview

Adapter Overview
Related Information
■
“Adapter Overview” on page 16
■
“Front Panel Connectors and LEDs” on page 17
Adapter Overview
The Quad Port 10GBase-T Adapter is a standalone PCIe 3.0 x8 card that can be low profile or
full height. This adapter has four independent ports, and you can configure and operate each
port a different speed. An RJ45 Ethernet cable connects to each port. The adapter is used for
virtualized cloud deployments and network virtualization.
Feature Specification
Data rate supported per port ■ 4x10GbE, where each port is split into four physical functions that operate
at 10Gbps.
■ 100BASE-T, 1000BASE-T, and 10GBASE-T.
Bus type
PCIe 3.0, 8.0 Gbps
Bus width x8, x4, x1 lane PCIe
Conforms to Ethernet standard
802.3
Boot ROM
32 Mb Flash
EMI FCC Class A
16 Oracle Quad Port 10GBase-T Adapter User's Guide • June 2019
