Connecting the Server Cables
These tasks describe how to connect and configure the network and serial ports before you
attempt to boot the server.
Step Description Links
1. Review the cabling requirements. “Cabling Requirements” on page 41
2. Review the front and rear panel connectors and ports. “Front Panel Components (Installation)” on page 12
“Rear Panel Components (Installation)” on page 13
“Identifying Ports” on page 42
3. Connect the management and data cables. “Connecting Data and Management Cables” on page 48
4. Secure the cables to the CMA. “Secure Cables to the CMA” on page 52
“Verify Operation of Slide Rails and CMA” on page 39
Related Information
■
“Rear Panel Components (Installation)” on page 13
■
“Installing the Server” on page 23
■
“Powering On the Server for the First Time” on page 53
Cabling Requirements
Prior to cabling and powering-on the server, gather the following network information:
■
Netmask
■
IP address for the SP
■
Gateway IP address
At a minimum, you must connect cables to these ports before powering-on the server for the
first time:
■
SP SER MGT port
Connecting the Server Cables 41
