Install the CMA
“Attach Slide Rail Assemblies to the Rack” on page 30
“Install the CMA” on page 35
“Verify Operation of Slide Rails and CMA” on page 39
Install the CMA
The cable management assembly is an optional assembly that you can use to route the server
cables in the rack.
1.
Unpack the CMA parts.
2.
Take the CMA to the back of the equipment rack and ensure that you have
adequate room to work around the back of the server.
Note - References to left or right in this procedure assume that you are facing the back of the
equipment rack.
3.
Remove tape to separate the parts of the CMA.
4.
Insert the CMA mounting bracket connector into the right slide rail until the
connector locks into place with an audible click.
No. Description
1 CMA mounting bracket
Installing the Server 35
