Install the Server
Install the Server
Use this procedure to install the server chassis, with mounting brackets, into the slide rail
assemblies that are mounted to the rack.
Caution - This procedure requires a minimum of two people because of the weight of the
server. Attempting this procedure alone could result in equipment damage or personal injury.
Caution - Always load equipment into a rack from the bottom up so that the rack will not
become top-heavy and tip over. Extend the rack's anti-tip bar or anti-tilt legs to prevent the rack
from tipping during equipment installation. See “Stabilize the Rack” on page 26 for more
information.
1.
Push the slide rails into the slide rail assemblies in the rack as far as possible.
2.
Raise the server so that the rear ends of the mounting brackets are aligned with
the slide rail assemblies that are mounted in the rack.
Installing the Server 33
