Connecting Data and Management Cables
Pin Signal Description Pin Signal Description
7 Green Ground 15 VGA 12C Serial Clock
8 Blue Ground
Related Information
■
“Front Panel Components (Installation)” on page 12
■
“Rear Panel Components (Installation)” on page 13
■
“Cabling Requirements” on page 41
Connecting Data and Management Cables
After you have connected these cables, see “Powering On the Server for the First
Time” on page 53 before connecting the AC power cords.
■
“Connect the SER MGT Cable” on page 48
■
“Connect the NET MGT Cable” on page 49
■
“Connect Ethernet Network Cables” on page 50
■
“Connect Other Data Cables” on page 51
Related Information
■
“Front Panel Components (Installation)” on page 12
■
“Rear Panel Components (Installation)” on page 13
■
“Cabling Requirements” on page 41
■
“Identifying Ports” on page 42
Connect the SER MGT Cable
The SP serial management port is labeled SER MGT. Use the SP SER MGT port only for server
management. This port is the default connection between the SP and a terminal or a computer.
Caution - Do not attach a modem to this port.
Connect an RJ-45 cable (Category 5 or better) from the SER MGT to a terminal
device.
48 SPARC T7-2 Server Installation Guide • March 2016
