BASIC PROGRAMING
TO CHANGE AND STORE A REGISTRATION
When creating a new registration it is not necessary to start from scratch is simpler and quicker to select
and modify an existing registration Start with a registration that is similar to the one that is required. .
We will therefore modify factory Overall Preset number A1.
1. Select overall preset A1 by pressing the overall preset button at the bottom of the Automatic Organ
Section and selecting overall preset 1 ensure that the left hand Led above the A/B button is
illuminated to indicate bank A is selected. When the Upper Keyboard is played there should now be
a basic Organ sound. The Flutes button should be the only one selected on the Upper conductor. If
this is not the case the registration has already been altered save these registrations to disk and
reload the factory settings as per the end of this basic programming section.
2. To change the organ sound adjust the Flutebars to modify the sound to a new setting the Sustain,
Motion Effect, Vibrato and Percussive can be selected at this time.
3. This new sound can now be stored into one of the four organ buttons situated above the upper
Flutebars. To store this sound.
a) Press the set button situated to the top right hand side of the control panel various lights will start
blinking.
b) Select the gray user button in the Upper Flute section, which is blinking.
c) Select one of the organ buttons for example Organ2, which will now start blinking.
Switch off the set button. The new organ sound is now saved in the Organ 2 button. It will only remain
there however when saved into an overall preset. Three more user organ sounds can be saved into
Organ 1 Organ 3 and Organ4. The same process can be followed for the Lower flutes using the lower
flute user button on the control panel above the lower Flutebars. It is therefore possible to save 4 Upper
organ and for Lower organ user presets into each overall preset. Before saving into an overall preset we
are going to alter a user sound in the Upper Orchestra 2 section.
In the example that follows, we are going to change the User Voice for Sax 1 in the Upper Orchestra
section. We will also make the new saxophone (ALTO 1) the lead voice - the other voices in the upper
section will remain unchanged and therefore can be selected via the upper conductor buttons.
1. Press the Flutes button in the upper section of the conductor (turns red LED off)
2. Press the Orchestra 2 button in the upper section (turns the red LED ON)
When you play the upper manual you hear a saxophone.
3. Press and Hold the gray User button in Upper Orchestra 2
Red LED above the Sax 1 button now flashes.
Screen will read:
Cursor Flashing
To Next Page
