Note: When selecting NTP as an input reference, do not select another ref-

erence (such as GNSS, IRIG, etc.) to work with NTP as a reference. NTP

should always be selected as both the Time and 1PPS input when it is

desired to use NTP as an input reference.

Example 4 – Time set manually by the User. Other references may or may

not be available

Note: In order for a manually set time to be considered valid and used to syn-

chronize VersaSync, a “User” needs to be created and enabled in the Refer-

ence Priority table. "The "User/User" Reference" on page158.

In this use case, the objective is to use a hand-set time, in combination with VersaSync's

oscillator as a 1PPS source as valid references.

Step-by-step procedure:

If necessary (see NOTE above), create a “User.”

Move the reference which has “User 0” in the Time column and “User 0” in the

1PPS column to the top of the table, with a Priority value of 1. Click the Enabled

checkbox.

For all other references, uncheck the Enabled checkbox, so that they are all dis-

abled.

If the objective is to use a manually set time as a

backup

to other references (such as

GNSS or IRIG):

Move the "User/User" reference to a place in the table that has a priority lower than

the references the "User/User" reference will be backing up. Make sure the

Enabled checkbox is selected.

With “User/User” enabled, if no other higher priority references are enabled or avail-

able (or if the higher priority references have since been lost), you can now manually

set the System time to the desired value (MANAGEMENT > OTHER: Time Man-

agement > System Time > Manual Time Set). See "System Time" on page138

for more information. VersaSync will go into synchronization using this set time once

you click the Submit button.

162

CHAPTER 3 • VersaSync User Manual Rev. 7.0

3.3 Managing References
