13.
Click Submit.
2.7.4 Configurable I/Os
2.7.4.1 Configuring a 1PPS Input
To configure a 1PPS Input:
1.
Navigate to INTERFACES > REFERENCES: PPS Input 0 (or: INTERFACES >
OPTIONCARDS: PPS Input 0).
2.
The PPS Input 0 Status window displays. Click Edit to open the configuration win-
dow:
2.7 Configuring Inputs/Outputs
CHAPTER 2 • VersaSync User Manual Rev. 7.0
47
