Orolia VersaSync User Manual

Note: Building the mating cables requires special tools. Contact ODU for
cable assemblies. Be advised that typical lead times are 12 to 16 weeks.
ETHERNET connector wiring:
1 through 8: A Ethernet Connect, 4 pairs, 1000bT
9 through 16: B Ethernet Connect, 4 pairs, 1000bT
POWER connector pinout
1: V
Main
, 10 to 32 V
DC
2: -not used-
3: V
Standby
, 10 to 32 V
DC
(Standby Power)
4: Ground return, standby power
5: Ground return, main power
1.5 Connectors and their Pinouts
CHAPTER 1 • VersaSync User Manual Rev. 7.0
13
