OSEE Lilmon 5 - Range; Matrix

Monitor Settings
29
5.2.7 Range
The Range menu item is used to set the Input Range as shown in Figure
5.2-11:
Figure 5.2-11 Range Menu
Table 5.2-7 Description of Range
Item
Default
Domain Range
Description
Options
Auto
Auto/64~940/0~1023
Refers to the range
of values your video
is encoded within, if
you don’t know the
specific range of your
video, just select
Auto
5.2.8 Matrix
The Matrix menu is used to set color Matrix as shown in Figure 5.2-11:
Figure 5.2-12 Matrix Menu
Table 5.2-8 Description of Color Matrix
