OSEE Lilmon 5 - Exposure Tools (False Color, Zebra)

MySets and Tools
49
ANAMORPHIC
INPUT SIGNAL
INPUT
OUTPUT
720P
1280x720
1920x568
2X
1080P/1080I
1920x1080
1920x540
720P
1280x720
1920x540
 Magnify
This item will magnify the image of anamorphic ratio to full-fill the
screen. Set
Anamorphic

Magnify
item as
On
, it will enlarge and
display the image at full screen, removing those useless blank bars,
as shown in Figure 6.1-5:
Figure 6.1-5 MAGNIFY
6.1.2 Exposure Tools
Lilmon 5 provides exposure tools including false color, zebra, waveform,
vector and histogram, as shown in Figure 6.1-6:
Figure 6.1-6 Expose Tools
Table 6.1-4 Description of Expose Tools
Tool
Items
Default
Domain
Range
Description
