OSEE Lilmon 5 - Page 59

MySets and Tools
51
Tool
Items
Default
Domain
Range
Description
Tone1
MAX
4%CV
1-100%CV
Set Tone 1’s maximum code
value for detecting areas of a
certain luminance range
Tone2 MIN
97%CV
0-99%CV
Set Tone 2’s minimum code
value for detecting areas of a
certain luminance range
Tone2
MAX
100%CV
1-100%CV
Set Tone 2’s maximum code
value for detecting areas of a
certain luminance range
WAVE
FORM
Style
LUMA
LUMA/RGB/
Parade
Set the type of the waveform
Size
Small
Small/
Large/
Bottom
Set the size of the waveform
Position
Top Right
Top Right/
Bottom
Right/
Top Left/
Bottom Left
Set the position of the
waveform, only available for
small size waveform
Density
50%
25%/50%
75%/100%
Set the density of the
waveform, the step is 1%
Opacity
100%
25%/50%
75%/100%
Set the transparency of the
waveform
Vector
Position
Top Right
Top Right/
Bottom
Right/
Top Left/
Bottom Left
Set the position of the vector
Gain
X1
X1/X2
Set the gain of vector
