OutBack Power FLEXmax 100 User Manual

Installation
12 900-0209-01-00 Rev A
Bracket Mount
The second mounting method uses brackets on the top and bottom of the controller. This method is
useful when mounting the controller next to an OutBack inverter system, as the conduit openings will
align. It is also useful for mounting without making advance measurements. The FLEXmax 100
controller comes with two identical brackets.
Figure 5 Mounting the Charge Controller (brackets)
To mount using brackets:
1.
Using two ¼” hex head lag screws, moun
t the lower
bra
cket with the tabs facing upward. Th
e mounting
surfa
ce must be strong enough to suppo
rt the added
weig
ht of the FLEXmax 10
0.
NOTE: OutBack i
s not responsible for damag
e
resulting from
inadequate mounting preparatio
n.
2.
Lower the FLEXmax 100 onto the bracket as sh
own
to the left.
The bracket
tabs can be inserted in one
of two positio
ns: forward or rear
.

To mount the controller flush against the wall, insert the
tabs in the forward slots as shown below.

To mount the controller 0.83” (2.1 cm) from the wall to
align with an OutBack mounting plate, insert the tabs in
the rear slots as shown below.
NOTE: The cha
rge controller can rest on the lower
bracket for the rest of the procedure, although it will
need at least one hand to steady it.
3.
Insert the upper bracket into the same
set of slots as
were used wit
h the lower bracket (forward or re
ar) as
s
hown to the left.
4.
Using two ¼” hex head lag screws, attach the uppe
r
bra
cket to the mounting surface as sh
own to the left.
Mounting i
s complete. Proceed to charge controller
wiring or other installation steps.
4
Forward
slot
Rear
slot
Rear
slot
Forward
slot
Bracket hole spacing: 5.13” (13.0 mm)
Vertical space between upper and lower
bracket holes: About 20" when mounted
