900-0209-01-00 Rev A 59
Specifications
Table 10 Electrical and Mechanical Specifications
Specification Value
Maximum Continuous Output Current 100 Adc
Maximum Input Current (short-circuit) 64 Adc
Nominal Battery System Voltage 24, 36, or 48 Vdc (automatically adjusted)
PV Open-Circuit Voltage 300 Vdc (highest open-circuit voltage before equipment damage)
Operating Voltage Range
Low 15 Vdc (lowest battery voltage for functionality)
High 290 Vdc temperature corrected V
oc
(operational maximum)
Standby Power Consumption ~2.5 W
Charge Cycle Three-stage
Minimum Battery Bank Size 100 Ahr
Charging (Output) Range 20 to 68 Vdc
Temperature Compensation Adjustable from 2 mV/cell/°C to 6 mV/cell/°C
Remote Interface RJ45 modular connector (CAT 5-style 8-wire twisted-pair cable)
Conduit Openings Sides, bottom (plugs inserted); 1⅜” diameter openings for 1” conduit size
Dimensions (H x W x D) 22.0” × 8.8” × 6.0” (47.1 cm × 22.4 cm × 15.2 cm)
Shipping Dimensions (D x W X L) 10.0” × 12.0” × 25.5” (25.4 cm × 30.5 cm × 64.8 cm)
Weight 18.3 lb (8.3 kg)
Shipping Weight 22.0 lb (9.9.kg)
Table 11 Environmental / Safety Specifications
Specification Value
Operating Temperature Range Ambient -20°C to 60°C (-13°F to 140°F)
Output Power Temperature Derating Ambient 25°C to 60°C (77°F to 140°F); controller begins derating at 25°C
Environmental Category Outdoor
Suitable for Wet Locations Yes
Ingress Protection Rating IP54
Relative Humidity Rating 4% to 100% Condensing
Enclosure Type Type 3R
Maximum Altitude Rating 10,000 ft
Overvoltage Category
PV: OV Cat II
Batt: OV Cat II
Regulatory Specifications
Listings
This product carries a listing report by ETL. It is listed to the following standards:
UL1741 — Inverters, Converters, Controllers and Interconnection System Equipment for Use With Distributed
Energy Resources — Issue: 2010/1/28 Ed: 2
CSA C22.2 — General Use Power Supplies, No. 107.1-01 — Issue: 2001/09/01 Ed:3 (R2011)
