OutBack Power FLEXmax 100 User Manual

Introduction
8 900-0209-01-00 Rev A
Components and Accessories
Table 1 Components Included
1 × FM 100 Charge Controller
2 × Mounting Bracket
1 × Silicone Grease Package
1 × Fan
Figure 1 Features & Wiring Cover
Battery Types
The default settings of the FLEXmax 100 charge controller are for lead-chemistry batteries intended for
deep discharge. These include all energy storage offered by OutBack Power as well as batteries for
marine, golf-cart, and forklift applications. They also include gel-cell batteries and absorbed glass-mat
(AGM) batteries. OutBack Power recommends the use of batteries designed specifically for renewable
energy applications. Lithium-based batteries and other advanced battery technologies may require
special charging considerations.
To remove the wiring compartment cover:
1. Using a P
hillips screwdriver, remo
ve the two screws from
the bottom of the comp
artment cover. (S
ee above.)
2.
Grasp the lower edge as shown. Swing the cover ou
t
while p
ulling downward.
Equalize
switch
Status indicators
with universal symbols
Easily accessible
wiring
compartment
Rainproof
enclosure
Cover screws

OutBack Power FLEXmax 100 Specifications

General

Brand	OutBack Power
Model	FLEXmax 100
Category	Controller
Language	English
