Specifications
62 900-0209-01-00 Rev A
Default Settings and Ranges
The settings in this table are as shown in the system display.
Table 12 FLEXmax Settings
Mode Menu Item
Setting
Value 24-volt 36-volt 48-volt
Charger
Absorb Voltage
Default 28.8 Vdc 43.2 Vdc 57.6 Vdc
Range Float setting to 68.0 Vdc
(Absorb) Time
Default 01.0 hours
Range 00.0 to 24 hours
Float
Default 27.6 Vdc 41.4 Vdc 55.2 Vdc
Range 20.0 Vdc to Absorbing setting
Rebulk Voltage
Default 24.0 Vdc 36.0 Vdc 48.0 Vdc
Range 10.0 Vdc to Float setting
Current Limit
Default 100 Adc
Range 5 to 100 Adc
Absorb End Amps
Default 00 Adc
Range 00 to 55 Adc
MPPT
MPPT Mode
Default
<Auto >
Range
<Auto> or U-Pick>
U-Pick VOC
Default 77% Voc
Range 40 to 90% Voc
Wakeup VOC Change
Default 3.0 Vdc 4.5 Vdc 6.0 Vdc
Range 1.5 to 9.5 Vdc
(Wakeup VOC) Time
Default 05 minutes
Range 05 to 15 minutes
Snooze Mode Amps
Default 0.6 Adc
Range 0.2 to 1.0 Adc
Temperature
Compensation
Mode
Default
<Wide >
Range
<Wide> or <Limited>
Slope
Default 5 mV
Range 2 to 6 mV
Lower Battery Voltage
Default 26.4 Vdc 39.6 Vdc 52.8 Vdc
Range 10 Vdc to Upper Battery Voltage setting
Upper Battery Voltage
Default 28.2 Vdc 42.3 Vdc 56.4 Vdc
Range Lower Voltage setting to 68.0 Vdc
Battery
Equalize
Equalization Voltage
Default 28.8 Vdc 43.2 Vdc 57.6 Vdc
Range Absorb Voltage setting to 68.0 Vdc
(Equalization) Hours
Default 01 hours
Range 1 to 7 hours
Automatic Battery
Equalization
Default 0 days
Range 0 to 250 days
Grid-Tie Mode
Enable Grid-Tie Mode
Default N
Range Y or N
Auxiliary
Output
Vent Fan
Default
<Off>
Range
<On, Auto, Off>
Enable
Voltage
Default 28.8 Vdc 43.2 Vdc 57.6 Vdc
Range 20.0 to 68.0 Vdc
PV Trigger
Default
<Off>
Range
<On, Auto, Off>
Active
Default Active High
Range Active High or Active Low
Enable
Voltage
Default 24.0 Vdc
Range 20 to 250 Vdc
Hold Time
Default 0 Vdc
Range 0 to 25 seconds
