OutBack Power FLEXmax 100 User Manual

Specifications
900-0209-01-00 Rev A 63
Table 12 FLEXmax Settings
Mode Menu Item
Setting
Value 24-volt 36-volt 48-volt
Auxiliary
Output
Error Output
Default
<Off>
Range
<On, Auto, Off>
Low Battery
Voltage
Default 23.0 Vdc 34.5 Vdc 46.0 Vdc
Range
20.0 to 68.0 Vdc
Night Light
Default
<Off>
Range
<On, Auto, Off>
Active
Default Active High
Range Active High or Active Low
Threshold
Default 10 Vdc
Range 5 to 250 Vdc
ON Time
Default 4 hours
Range 00 to 23 hours
Hysteresis
Time
Default 1 minute
Range 1 to 255 minutes
Rapid Shutdown
Default
<Off>
Range
<On, Auto, Off>
Float
Default
<Off>
Range
<On, Auto, Off>
Diversion: Relay
Default
<Off>
Range
<On, Auto, Off>
Active
Default Active High
Range Active High or Active Low
Relative
Voltage
Default 0 Vdc
Range 0.0 to 5.0 Vdc
Hysteresis
Default 0.2 Vdc
Range 0.0 to 12.0 Vdc
Hold
Default 0.1 second
Range 0.0 to 25 seconds
Delay
Default 0.0 seconds
Range 0.0 to 24 seconds
Diversion: Solid St
Default
<Off>
Range
<On, Auto, Off>
Relative
Voltage
Default 0.0 Vdc
Range 0.0 to 5.0 Vdc
Hysteresis
Default 0.2 Vdc
Range 0.0 to 12.0 Vdc
Hold
Default 0.1 second
Range 0.0 to 25 seconds
Delay
Default 0.0 seconds
Range 0.0 to 24 seconds
Low Batt Disconnect
Default
<Off>
Range
<On, Auto, Off>
Disconnect
Default 27.2 Vdc 40.8 Vdc 54.4 Vdc
Range
20.0 to 68.0 Vdc
Reconnect
Default 28.8 Vdc 43.2 Vdc 57.6 Vdc
Range
20.0 to 68.0 Vdc
Disconnect
Delay
Default 01 second
Range 0 to 250 seconds
Remote
Default
<Off>
Range
<On, Auto, Off>
