Installation
900-0209-01-00 Rev A 23
Figure 16 Wiring Diagram — System with Inverter
NOTE: System-specific wiring is not shown.
Photovoltaic (PV) Array
HUB
Charge Controller
DC
Disconnect
Panel
Inverter
Battery Bank
PV PV PV
HUB/DEVICE
CAT 5E
Ground
PV+ PV– BAT– BAT+
Ground Bus Bar
Shunt
Terminal Bus Bar
(
Ne
g
ative
)
RTS
Inverter
DC Disconnect
MATE3s
HUB/
MATE
Ground
