1.4.1 Quick Setup Diagram
BEFORE INSTALLING ANYTHING WE STRONGLY RECOMMEND THAT YOU
CONNECT YOUR CAMERAS TO YOUR DVR AND TEST YOUR SYSTEM FIRST.
WE CHECK EVERYTHING TO MAKE SURE IT IS WORKING WHEN IT LEAVES US
BUT OCCASIONALLY THINGS FAIL AND IT IS BETTER TO KNOW NOW THAN
AFTER YOU HAVE FITTED EVERYTHING!
1. Connecting your cameras: Your Cameras have 2 plugs attached, one is a BNC
connector (for the video) the other is for power. Connect these plugs into the
sockets on the end of one of the cables included in the kit.
2. Connecting your DVR: At the other end of the cable there are two plugs, these
connect your camera to the DVR and also to the power supply. You will also
need to connect your DVR to a TV or monitor. We have included a HDMI cable
but you can also use the RCA (Video Out) socket or the VGA Socket on the
back of the DVR.
3. Switch on: Once you have connected all the cables successfully connect the
DVR & Camera power leads to a power outlet. Switch on your TV and select the
HDMI socket you have DVR connected to.
