Pacific Power Source UPC-3 User Manual

SECTION 4 OPERATION
52
4.5.2.1 TIME BASED TRANSIENT EXAMPLE (cont)
Press 1, ENTER, 1, ENTER, 1, to select Waveform 1 on all three phases.
TRANSIENT: PRGM #4 SEGMENT #2 OF 2
T=0.01 Va=80 Vb=80 Vc=80
F=400 WFa=1 WFb=1 WFc=1
Press ENTER, now we are starting segment 3 of 3.
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=0.01 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press ENTER, ENTER, .07, ENTER, to select default segment 3 of 3 and a time 70 milliseconds.
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=.07 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press 108, ENTER, 108, ENTER, 108, ENTER, to select 108 volts on all three phases.
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=0.07 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press 400, ENTER, to select 400 Hz.
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=0.07 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
