5.2 Functional specifications
Analog Output 4-20 mA isolated, 800 max, load, isolated, field-programmable
Digital Output RS232, 3-conductor
Power Input 24.0 VDC ±4 VDC @ 1.2 A maximum
Cable (Power Input and
Analog Output)
Standard: 10 ft (3 m), 4-conductor, shielded, P/N X4(10); lengths up to 4000 ft. Optional:
lengths to 450 ft. (137 m) available
Cable (Digital Output)
6 ft (2 m), 3-conductor, shielded, P/N 704-667, 668, 669, or 670
Connector: DB9 male, DB9 female, DB25 male, or DB25 female
Lengths: up to 4,000 ft (1,200 m)
Operating Temperature
Standard: +45oC (+113oF)
Optional: +60° or +70°C (+140°F or +158oF)
Ambient Temperature Range Standard 45°C unit: -20° to +40°C (-4° to +104°F) Optional 60°C unit: -5 to 55°C (23 to 131°F)
Sample Gas Pressure Range: 20 psig maximum
5.3 Physical specifications
Sensor Wetted Materials
Standard: 316 SS, glass, and Viton™ o-rings
Optional: Hastelloy, Monel, or Titanium with Chemraz™ o-rings
Dimensions
Weatherproof unit: 9.53” (H) x 5.71” (D) (242 x 145 mm)
Explosion-proof unit: 10.47” (H) x 5.71” (D) (266 x 145 mm)
Weight 9.5 lb (4.3 kg)
Connections
Electrical: 3/4 in. NPTF conduit and 6-terminal, removable connector
Process: 1/4 in. NPTF inlet and outlet
Environmental
Weatherproof:
Class I Div. 1 Groups A, B, C and D
Class II, III Div. 1 Groups E, F and G
Tamb 55°C T6 Type 4X
Flameproof:
ITS12ATEX17703X
IECEx ITS 12.0058X
II 2 G Ex d IIC T6 Gb
IP66 -20°C < Tamb < +55°C
All conduit entries 3/4” NPT
CE:
EMC 2014/30/EU
PED 2014/68/EU
ATEX 2014/34/EU
Lloyd’s Registry approval
Note: For CE compliance, the power and I/O cables must be shielded. All cables must be
terminated within the cable gland at the XMO2.
Note: See the Certification Drawings in Appendix B, Outline and Installation Drawings, for
additional details.
