5.6 Calibration specification
A B C
XMO2 -
A: Transmitter Model
XMO2
B: Range of Oxygen Output
1 - 0-1%
2 - 0-2%
3 - 0-5%
4 - 0-10%
5 - 0-21%
6 - 0-25%
7 - 0-50% (atmospheric pressure compensation XMO2 hardware required)
8 - 0-100% (atmospheric pressure compensation XMO2 hardware required)
A - 90-100% (atmospheric pressure compensation XMO2 hardware required)
B - 80-100% (atmospheric pressure compensation XMO2 hardware required)
S - Special
C: Compensation Signal
1 - Background gas only (standard gas N
2
/CO
2
)
2 - Atmospheric pressure only (standard pressure range of 700-800 mm of Hg)
3 - Background gas only (special gas)
4 - Atmospheric pressure only (special range)
5 - Background gas and atmospheric pressure (standard gas N
2
/CO
2
and standard pressure range of
700-800 mm of Hg)
7 - 0, 2, 10, 21% O
2
in N
2
and 14% CO
2
/N
2
S - Background gas and atmospheric pressure (special gas and special pressure range)
