Appendix
FPΣ User's Manual
294
No. Name Default Values
8
1)
Data register hold area start address 32710 0–32763
10
Link relay hold area start address for PLC Link 0 (in word
units)
64 0–64
11
Link relay hold area start address for PLC Link 1 (in word
units)
128 64–128
12
Link register hold area start address for PLC Link 0 128 0–128
13
Link register hold area start address for PLC Link 1 256 128–256
14
1)
Step ladder hold/non-hold Non-hold Hold/Non-hold
1)
These settings are effective if the optional backup battery is installed
If no backup battery is used, do not change the default settings. Otherwise proper functioning of hold/non-hold
values cannot be guaranteed.
Act on Error
No. Name Default Values
4 Battery error indication Disable
Disable: When a battery error occurs, a self-diagnostic
error is not issued and the ERROR/ALARM LED will not
flash.
Enable: When a battery error occurs, a self-diagnostic
error is issued and the ERROR/ALARM will LED flash.
4
DF-, P-function leading/falling
edge detection
Holds result Holds result/disregards result
20
Duplicate output Enable Fixed
23
I/O verification error Stop Stop/Continue
26
Operation error Stop Stop/Continue
Time-Out
No. Name Default Values
30
Watchdog timer time-out 400.0ms Fixed
31
Multi-frame communication time 6500.0ms 10.0–81900.0ms
32
Data transfer delay 10000.0ms 10.0–81900.0ms
34 Constant scan time 0.0ms
0.0–350.0ms
0.0: Normal scan (non-
constant)
PLC Link
No. Name Default Values
46
PLC Link 0 and 1 allocation setting Normal Normal/Reverse
47
PLC link 0 - Highest station number in network 16 1–16
40
PLC link 0 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
42
PLC link 0 - Link relays - Send area - Start sending from this word
address
0 0–63
43
PLC link 0 - Link relays - Send area - Number of words to send 0 0–64 words
41
PLC link 0 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
44
PLC link 0 - Link registers - Send area - Start sending from this
0 0–127
