FPΣ User's Manual
12.6 System Registers
295
No. Name Default Values
word address
45
PLC link 0 - Link registers - Send area - Number of words to send 0 0–127 words
57
PLC link 1 - Highest station number in network 16 1–16
50
PLC link 1 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
52
PLC link 1 - Link relays - Send area - Start sending from this word
address
64 64–127
53
PLC link 1 - Link relays - Send area - Number of words to send 0 0–64 words
51
PLC link 1 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
54
PLC link 1 - Link registers - Send area - Start sending from this
word address
128 128–255
55
PLC link 1 - Link registers - Send area - Number of words to send 0 0–127 words
High-Speed Counter, Pulse Catch Input, Interrupt Input
No.
Name Default Values
400
High-speed counter:
Channel 0
Unused
• Two-phase input (X0, X1)
• Two-phase input (X0, X1), Reset input (X2)
• Incremental input (X0)
• Incremental input (X0), Reset input (X2)
• Decremental input (X0)
• Decremental input (X0), Reset input (X2)
• Incremental input (X0), Decremental input (X1)
• Incremental input (X0), Decremental input (X1), Reset input (X2)
• Counter input (X0), Incremental/decremental control input (X1)
• Counter input (X0), Incremental/decremental control input (X1),
Reset input (X2)
400
High-speed counter:
Channel 1
Unused
• Incremental input (X1)
• Incremental input (X1), Reset input (X2)
• Decremental input (X1)
• Decremental input (X1), Reset input (X2)
401
High-speed counter:
Channel 2
Unused
• Two-phase input (X3, X4)
• Two-phase input (X3, X4), Reset input (X5)
• Incremental input (X3)
• Incremental input (X3), Reset input (X5)
• Decremental input (X3)
• Decremental input (X3), Reset input
• Incremental input (X3), Decremental input (X4)
• Incremental input (X3), Decremental input (X4), Reset input
• Counter input (X0), Incremental/decremental control input (X5)
• Counter input (X3), Incremental/decremental control input (X4),
Reset input X5)
