FPΣ User's Manual
12.6 System Registers
297
TOOL Port
No. Name Default Values
412
TOOL port - communication mode
MEWTOCOL-COM
Slave
MEWTOCOL-COM
Slave/Program
controlled
410
TOOL port -station number 1 1–99
415
TOOL port - baud rate 115200 baud
115200/57600/3840
0/19200/9600/4800/
2400 baud
413
TOOL port - sending data length 8 bits 7 bits/8 bits
413 TOOL port -sending parity check With-Odd
None/With-
Odd/With-Even
413
TOOL port - sending stop bit 1 bit 1 bit/2 bits
413
TOOL port - sending start code No-STX No-STX/STX
413 TOOL port - sending end code/reception done condition CR
CR/CR+LF/ETX/Non
e
420
TOOL port- -receive buffer starting address 0 0–32762
421
TOOL port - receive buffer capacity 0 0-2048
412
TOOL port - modem connection Disable Disable/Enable
COM Port
No. Name Default Values
412 COM port 1 - communication mode
MEWTOCOL-COM
Master/Slave
MEWTOCOL-COM
Master/Slave/Program
controlled/PLC Link/Modbus
RTU Master/Slave
410
COM port 1 -station number 1 1–99
415 COM port 1 - baud rate
1) 2)
9600 baud
115200/57600/38400/19200/960
0/4800/2400 baud
413
COM port 1 - sending data length 8 bits 7 bits/8 bits
413
COM port 1 -sending parity check
1)
With-Odd None/With-Odd/With-Even
413
COM port 1 - sending stop bit 1 bit 1 bit/2 bits
413
COM port 1 - sending start code
1)
No-STX No-STX/STX
413
COM port 1 - sending end code/reception done
condition
1)
CR CR/CR+LF/ETX/None
416
COM port 1- -receive buffer starting address 0 0–32762
417
COM port 1 - receive buffer capacity 0 0-2048
412
COM port 1 - modem connection Disable Disable/Enable
412 COM port 2 - communication mode
MEWTOCOL-COM
Master/Slave
MEWTOCOL-COM
Master/Slave/Program
controlled/Modbus RTU
Master/Slave
411
COM port 2 - station number 1 1–99
415 COM port 2 - baud rate 9600 baud
115200/57600/38400/19200/960
0/4800/2400
414
COM port 2 - sending data length 8 bits 7 bits/8 bits
414
COM port 2 - sending parity check With-Odd None/With-Odd/With-Even
414
COM port 2 -sending stop bit 1 bit 1 bit/2 bits
