3.2 Input and Output Specifications
23
Internal circuit diagram
• C32 - NPN
+
-
[Y0, Y1, Y3, Y4]
+
-
[Y2, Y5-YF]













24V DC
24V DC
5-24V DC

5-24V DC

1
Internal circuit
5
Load
2
Output circuit
6
External power supply
3
Output indicator LED
7
Load power supply
4
Output
8
Phase fault protection circuit
