7.1 G
7.1.1 GROUP FEATURES
Description
This PBX supports various types of groups.
1. Trunk Group
CO lines can be grouped into trunk groups based on carrier, CO line type, etc. Several settings can be
assigned on a trunk group basis. All CO lines belonging to a trunk group follow the programming for that
trunk group.
® 5.1 [3-1-1] Trunk Group—TRG Settings
® [402] LCOT Trunk Group Number
Each CO line can belong to only one trunk group. CO lines are assigned to a trunk group based on their
port numbers (for ELCOT/LCOT and PRI cards) or their channel numbers
(for T1 cards).
2. Extension User Group
Extensions can be
grouped into extension user groups. Extension user groups then compose the following
groups:
a. Tenant (® 17.1.3 Tenant Service)
b. Call Pickup Group (See below.)
c. Paging Group (See below.)
Every extension must belong to one extension user group and cannot belong to more than one extension
user group.
® 5.6 [3-2] Extension Group
® [603] Extension User Group
Assignable Extensions: Proprietary telephone (PT)/single line telephone (SLT)/portable station (PS)/
T1-OPX
[Example]
Extension User
Group 1
Extn. 100 Extn. 101
Extension User
Group 2
Extn. 102 Extn. 103
Extension User
Group 3
Extn. 104 Extn. 105
Extension User
Group 4
Extn. 106 Extn. 107
Call Pickup Group
Using the Group Call
Pickup feature, extensions can answer any calls within the call pickup group to which
they belong. One extension user group can belong to several call pickup groups. (® 3.1.9 Call Pickup)
® 5.7 [3-3] Call Pickup Group
® 5.8 [3-3] Call Pickup Group—All Setting
® [650] Extension User Groups of a Pickup Group
136 Feature Manual Document Version 2013-05
7.1.1 GROUP FEATURES
