• Network Type (BRI only)
Each BRI port can be set to the requirements of each country/area.
® 3.13 [1-1] Slot—Port Property - BRI Port—Network—
Network Type
® [420] BRI Network Type
• L1 Active Mode and L2 Data Link Mode (BRI only)
The active mode of Layer 1 (L1) and the data link mode of Layer 2 (L2) can be selected individually
(Permanent or Call by Call) on an ISDN port basis.
3.13 [1-1] Slot—Port Property - BRI Port—Network
®
L1 Mode
® L2 Mode
® [425] BRI Layer 2 Active Mode
• TEI Assignment Mode (BRI only)
The Terminal Endpoint Identifier (TEI) assignment mode can be selected on an ISDN port basis
® 3.13 [1-1] Slot—Port Property - BRI Port—Network—
TEI Mode
® [427] BRI TEI Mode
• Bearer Mode
The bearer mode can be assigned on an extension basis.
® 6.1 [4-1-1] Wired Extension—Extension Settings—Option 7—
ISDN Bearer
® 6.10 [4-2-1] Portable Station—Extension Settings—Option 7— ISDN Bearer
• Automatic ISDN Configuration
ISDN (BRI) port configuration can be set automatically through system programming.
® 2.5.2 Tool—BRI Automatic Configuration
The following items will be set by making and receiving a call using the subscriber number assigned for
each ISDN (BRI) port:
– L1 Active Mode
– L2 Data Link Mode
– Access Mode (Point-to-Point/Point-to-Multipoint)
– TEI Assignment Mode (Fix 00–63/Automatic)
PC Programming Manual References
2.5.2 Tool—BRI Automatic Configuration
3.12 [1-1] Slot—Card Property - BRI type/PRI type
3.13 [1-1] Slot—Port Property - BRI Port
3.14 [1-1] Slot—Port Property - BRI Port—Connection Command
3.15 [1-1] Slot—Port Property - PRI Port
3.16 [1-1] Slot—Port Property - PRI Port—Connection Command
4.4 [2-3] Timers & Counters—Dial / IRNA / Recall / Tone—
Dial—Extension Inter-digit
4.17 [2-9] System Options—Option 2— ISDN en Bloc Dial—[#] as End of Dial for en Bloc mode
6.1 [4-1-1] Wired Extension—Extension Settings
→Main— Extension Number
→Option 7— ISDN Bearer
6.10 [4-2-1] Portable Station—Extension Settings—Option 7— ISDN Bearer
5.5 [3-1-4] Dialling Plan—Auto Assign
PT Programming Manual References
[420] BRI Network Type
[424] BRI Layer 1 Active Mode
[425] BRI Layer 2 Active Mode
[426] BRI Configuration
[427] BRI TEI Mode
Feature Guide 235
1.21.1 Integrated Services Digital Network (ISDN)
