1.30.6 Network ICD Group
Description
An Incoming Call Distribution (ICD) Group can include up to 4 destinations at other PBXs in a private network,
including the floating extension number of another ICD Group. This is done by assigning a virtual PS as a
member of the ICD Group, and then setting the number of a destination at another PBX as the forwarding
destination for that virtual PS. This allows multiple ICD groups at remote locations to receive calls together.
PBX-2
PBX-1
Private network
PBX-5
PBX-4
PBX-3
ICD
Group
ICD
Group
ICD
Group
ICD
Group
Telephone Company
ICD Group
Virtual PS 1
Virtual PS 2
Virtual PS 3
Virtual PS 4
Conditions
• Hardware Requirement:
The KX-TDA0920 SD Memory Card for Software Upgrade to Enhanced Version must be installed in the
PBX that will support virtual PSs.
• The conditions for 1.2.2.3 Outside Destinations in Incoming Call Distribution Group also apply to this
feature.
PC Programming Manual References
4.17 [2-9] System Options—Option 4— Send CLIP of CO Caller to ISDN—when ICD Group with Cellular
Phone
Feature Guide 355
1.30.6 Network ICD Group
