VM (DPT) Group Assignment:
The VPS is connected to the DPT ports of the PBX. These DPT ports, as well as VM (DPT) group settings,
must be configured to allow DPT (Digital) Integration, as shown in the following [Programming Example of
Extension Port] and [Programming Example of VM (DPT) Group].
[Programming Example of Extension Port]
DPT Property
VM (DPT)
Group 1
Slot
3
3
:
4
4
:
5
5
:
6
6
Port
1
2
:
1
2
:
1
2
:
1
2
Extn. No.
101
102
:
201
202
:
301
302
:
401
402
Type*
1
VM (DPT)
VM (DPT)
:
VM (DPT)
VM (DPT)
:
Not assignable
Not assignable
:
Not assignable
Not assignable
Unit No.
of VPS*
2
1
1
:
2
2
:
Not assignable
Not assignable
:
Not assignable
Not assignable
Port No.
of VPS*
3
1
2
:
1
2
:
Not assignable
Not assignable
:
Not assignable
Not assignable
Port Type
DPT
DPT
:
DPT
DPT
:
SLT
SLT
:
SLT
SLT
VM (DPT)
Group 2
VM (DTMF)
Group 1
VM (DTMF)
Group 2
*1
® 3.4 [1-1] Slot—Port Property - Extension Port— DPT Type—Type
® [601] Terminal Device Assignment
*2
® 3.4 [1-1] Slot—Port Property - Extension Port— DPT Type—VM Unit No.
*3
® 3.4 [1-1] Slot—Port Property - Extension Port—
DPT Type—VM Port No.
[Programming Example of VM (DTMF) Group]
VM (DTMF)
Group No.
1
2
Group
Name
Company C
Company D
Service
Mode
AA
VM
Floating
Extension
No.
300
400
1
301
401
…
…
…
Extension No. of
Port Connected to
VPS Port
2
302
402
® 5.23 [3-8-2] VM(DTMF) Group—Group Settings
[Programming Example of VM (DPT) Group]
VM (DPT) Group No.
1
2
Floating Extension No.*
1
500
200
Group Name*
2
Company A
Company B
*1
® 5.20 [3-7-2] VM(DPT) Group—Unit Settings— Floating Extension No.
® [660] VM Group Floating Extension Number
*2
® 5.20 [3-7-2] VM(DPT) Group—Unit Settings—
Group Name
2. Incoming Calls to VM Group
When incoming calls are received at the floating extension number of the VM group, calls will hunt starting
at the lowest VM port number. In this case, the FWD and DND settings (® 1.3.1 Call Forwarding (FWD)/
Do Not Disturb (DND)) for each extension port are disregarded.
It is programmable whether the calls queue when all extension ports in the group are busy through system
programming. If the queuing is disabled through system programming, the call will be redirected to the
destination, assigned on the trunk group which receives the call, by the Intercept Routing feature.
