Case 1:
Extension 1012 of PBX-1 dials extension number "1011".
® The dialled number is found at the local PBX, so extension 1012 of PBX-1 is connected to extension
1011 of PBX-1.
Case 2:
Extension 1012 of PBX-1 dials extension number "1033".
® The dialled number is not found at the local PBX, so the call is redirected to the specified TIE Line, and
extension 1012 of PBX-1 is connected to extension 1033 of PBX-2.
Case 3:
A public trunk call directed to extension 1033 arrives at PBX-1.
® The target extension number is not found at the local PBX, so the call is redirected to the specified TIE
Line, and the call is connected to extension 1033 of PBX-2.
– Hardware Requirement:
The KX-TDA0920 SD Memory Card for Software Upgrade to Enhanced Version
– System programming is required to enable this feature.
– If a dialled number is not found at a remote PBX, the call cannot be redirected to the local PBX to
search for a matching number.
• When a TIE line call arrives at a busy extension which has disabled Call Waiting, the caller will hear a busy
tone. If required, Intercept Routing—Busy/DND can be activated.
• The Inter-digit time can be assigned for TIE line calls.
® 4.4 [2-3] Timers & Counters—Miscellaneous—
Incoming Call Inter-digit Timer—TIE
PC Programming Manual References
3.13 [1-1] Slot—Port Property - BRI Port—Network Numbering Plan— Trunk Property
3.15 [1-1] Slot—Port Property - PRI Port—Network Numbering Plan— Trunk Property
3.18 [1-1] Slot—Port Property - T1 Port— Trunk Property
3.24 [1-1] Slot—Port Property - E1 Port— Trunk Property
3.27 [1-1] Slot—Port Property - EM Port— Trunk Property
4.4 [2-3] Timers & Counters—Miscellaneous— Incoming Call Inter-digit Timer—TIE
4.8 [2-6-1] Numbering Plan—Main—Features
→ Idle Line Access (Local Access)
→ Trunk Group Access
→ TIE Line Access
4.8 [2-6-1] Numbering Plan—Main—Other PBX Extension
4.11 [2-7-1] Class of Service—COS Settings—TRS— TRS Level—Day, Lunch, Break, Night
4.17 [2-9] System Options—Option 4— Private Network—TIE Call by Extension Numbering (Optional SD
Card Required)
5.1 [3-1-1] Trunk Group—TRG Settings—Main— COS
11.1 [9-1] TIE Table
12.2 [10-2] DIL Table & Port Settings
→DIL— Trunk Property
→DIL— DIL Destination—Day, Lunch, Break, Night
→DDI / DID / TIE / MSN
12.3 [10-3] DDI / DID Table— DDI / DID Destination—Day, Lunch, Break, Night
PT Programming Manual References
[453] DID Destination
[500] Trunk Group Number
330 Feature Guide
1.30.1 TIE Line Service
