Panasonic KX-TDA30

1.20 Proprietary Telephone (PT) Features
Feature Guide 247
1.20.4 Display Information
Description
A display PT shows the user the following information while making or receiving calls if they are available:
Conditions
• Multilingual Display
Each extension can select its display language through personal programming (Display Language
Selection).
• Display Contrast
It is possible to adjust the display contrast through personal programming (Display Contrast Selection).
This is available only for DPTs.
• Display Backlight
Each extension can select its display backlight on or off through personal programming (Display
Backlight Selection). This is available for the KX-T7633, KX-T7636 and IP-PTs.
• Characters (name) or digits (number) exceeding the display's size limitation are not displayed. In this
case, information which have been programmed is hidden, but not altered.
Programming Manual References
PC Programming Manual
2.8.17 [2-9] System Options—Option 5—PT Feature Access—No. 1–8
2.10.1 [4-1-1] Wired Extension—Extension Settings
→ Option 4—Display Language
→ Option 5—Incoming Call Display
Display Item Display Example Condition
The extension number and name of the calling
or called extension, or incoming call distribution
group
123: Tom Smith –
Status of the called extension 123: Busy –
The number and name of the optional device Door 02: 1st Door –
The dialled telephone number 1234567890 –
The received call information
a) Caller's name
b) Caller's number
c) Trunk number/name
d) Original Destination, if the call is forwarded
e) DDI/DID/MSN name or number
ABC Company
12345678
Line 001: Sales
→102:Mike
Panasonic
The first line message can be
either (a), (c), or (e) at each
extension through system
programming.
Call charge fee during a trunk call.
12.35
The currency, position of the
currency symbol, and the
decimal point are
programmable.
Call duration during a trunk call. Line 001 11:02'28 –
