2.2 System Configuration—Software
396 Feature Guide
2.2.2 Group
Description
This PBX supports various types of groups.
1. Trunk Group
Trunks can be grouped into a specified number of trunk groups (e.g., for each carrier, trunk type, etc.).
Several settings can be assigned on a trunk group basis. All trunks belonging to a trunk group follow
the assignment determined for that trunk group.
→ 2.9.1 [3-1-1] Trunk Group—TRG Settings
→ [402] LCOT/BRI Trunk Group Number
One trunk can belong to only one trunk group on a port or channel basis.
Port basis: ELCOT/LCOT/DID/E & M/ISDN-BRI/ISDN-PRI23/ISDN-PRI30
Channel basis: E1/T1
2. Extension User Group
The PBX supports extension user groups, each of which is used to compose the following groups:
a) Tenant (→ 2.2.3 Tenant Service)
b) Call Pickup Group (See below.)
c) Paging Group (See below.)
Every extension must belong to one extension user group, but cannot belong to more than one
extension user group.
→ 2.9.4 [3-2] User Group
→ [603] Extension User Group
Assignable Extensions: PT/SLT/PS/ISDN Extension/T1-OPX
[Example]
2.1 Call Pickup Group
Using the Group Call Pickup feature, extensions can answer any calls within a specified group. One
extension user group can belong to several call pickup groups.(→ 1.4.1.3 Call Pickup)
→ 2.9.5 [3-3] Call Pickup Group
→ 2.9.6 [3-3] Call Pickup Group—All Setting
→ [650] Extension User Groups of a Pickup Group
Extension
User Group 1
Extn. 100 Extn. 101
Extension
User Group 2
Extn. 102 Extn. 103
Extension
User Group 3
Extn. 104 Extn. 105
Extension
User Group 4
Extn. 106 Extn. 107
To Next Page
