Panasonic Lumix DMC-FZ2000 User Manual

15
1. Before Use
31
47
32 33 34
48
36
35
45
44
46
43
49
37
38
39
40
41
42
31
Touch screen (P48)/monitor (P316)
32
Eyecup (P337)
33
Viewfinder (P36)
34
Eye sensor (P37)
35
[AF/AE LOCK] button (P102)
36
Focus mode lever (P87, 100)
37
[Q.MENU] (Quick Menu) button (P53)/
[Fn5] button (P55)
38
[(] (Playback) button (P182)
39
[DISP.] button (P45, 47)
40
Cursor buttons (P45)
3/[ ] (ISO sensitivity) (P105)
1/[ ] (White Balance) (P107)
2/[ ] (Auto Focus Mode) (P91)
4/[
AF#] (AF Macro) (P111)
41
[MENU/SET] button (P45, 51)
42
[ ] (Delete/Cancel) button (P189)/
[Fn6] button (P55)
43
Speaker (P230)
44
[REMOTE] socket (P315)
45
Card door (P25)
46
DC coupler cover (P315)
• When using an AC adaptor, ensure that the
Panasonic DC coupler (optional) and AC
adaptor (optional) are used.
47
Battery door (P24)
48
Release lever (P24)
49
Tripod mount (P341)
• It may not be possible to attach and securely
fasten a tripod with a screw length of 5.5 mm
(0.22 inch) or more to the camera. Doing so
may also damage the camera.
∫ About the function button ([Fn8] to
[Fn12])
• Function buttons ([Fn8] to [Fn12]) (P55) are
touch icons. Touch the [ ] tab on the
recording screen to display them.

Panasonic Lumix DMC-FZ2000 Specifications

General

Sensor	1-inch High Sensitivity MOS Sensor
Resolution	20.1MP
Aperture	f/2.8-4.5
ISO Range	ISO 125-12800 (expandable to ISO 80-25600)
Image Stabilization	5-Axis Hybrid O.I.S.
Max Shutter Speed	1/4000 sec
Built-in Flash	Yes
External Flash	Yes, via hot shoe
Storage Media	SD/SDHC/SDXC Memory Card
Video Recording	4K UHD at 30p/24p, Full HD at 60p
Viewfinder	2, 360k-dot OLED Live View Finder
Screen	3.0-inch 1, 040k-dot Free-Angle Touch LCD
Connectivity	Wi-Fi, USB 2.0, HDMI
Battery Life	Approx. 350 shots (CIPA)
Weight	966 g with battery and SD card
Dimensions	137.6 x 101.9 x 134.7 mm (5.42 x 4.01 x 5.30 inch)
