To Next PageTo Next PageWhat to do if overload protective function activates and cannot clear alarm on Panasonic Engine?
If the overload protection activates on your Panasonic Engine and you cannot clear the alarm, wait for at least 10 seconds after the alarm output. Then, clear the alarm using the Alarm Clear (A-CLR) signal.
How to release a tripped motor that cannot activate Servo-ON in Panasonic Engine?
To release a tripped motor condition on your Panasonic Engine, ensure the alarm clear input (A-CLR) CN X5 pin 3 is ON for at least 120 ms.
General| Motor Type | AC Servo Motor |
|---|---|
| Protection Class | IP65 |
| Encoder Type | Incremental |
| Feedback | Encoder feedback |
| Ambient Temperature | 0 °C to +40 °C (without freezing) |
| Storage Temperature | -15 °C to +70 °C (without freezing) |
