101
[Connections and Settings in Position Control Mode]
Connections and
Settings in Position
Control Mode
PrNo. Parameter Name Function/Content
The parameter sets driving conditions during deceleration after alarm is
generated as a result of activation of any of protective functions of the driver, or
after the motor stops.
(DB: Dynamic Brake operation)
Also see Timing Chart “After an Alarm event” on Page 33 of Preparation edition.
The parameter sets the following:
1) Driving conditions during deceleration or after stop
2) Clear operation of the deviation counter
after Servo-OFF (SRV-ON signal: CN X5 pin 2 turns on off) is turned on.
(DB: Dynamic Brake operation)
Also see Timing Chart “Servo-ON/OFF Operation When the Motor is Stopped” on
Page 34 of Preparation edition.
The parameter enables you to set time from when the brake release signal (BRK-
OFF:CN X5 pin 11) turns off until the motor becomes de-energized (servo free),
when you turn on Servo-OFF while the motor is stopped.
Also see Timing Chart “Servo-ON/OFF Operation When the Motor is Rotating” on
Page 34 of Preparation edition.
68
69
6A
Sequence at alarm
Sequence at
Servo-OFF
Mech. break action
set-up at motor
standstill
0 - 3
0 - 7
[0]
0 -
100
[0]
Settings
[0]
1
2
3
During Deceleration
DB
Free run
DB
Free run
After stop
DB
DB
Free
Free
Driving Conditions
State of Deviation
Counter
Cleared
Cleared
Cleared
Cleared
• In order to prevent subtle travel/drop
of the motor (work) due to the action
delay time (tb) of the brake, set as
follows:
Setting of Pr6A ≥ tb
• Pr6A is set in the unit of (setting) ×
2ms.
• Refer to Timing Chart of “Servo-ON/
OFF Operation When the Motor is
Stopped” on Page 34.
ON
SRV-ON
BRK-OFF
Actual brake
Motor energized
Release
OFF
Retained
Release
Energized
Retained
De-energized
Pr6A
tb
Standard Default Setup: [ ]
Settings
[0]
1
2
3
4
5
6
7
During Deceleration
DB
Free run
DB
Free run
DB
Free run
DB
Free run
After stop
DB
DB
Free
Free
DB
DB
Free
Free
Driving Conditions
State of Deviation
Counter
Cleared
Cleared
Cleared
Cleared
Retained
Retained
Retained
Retained
Range of
Settings
