23
8.2. Disassembly Flow Chart
8.3. Main Components and P.C.B. Locations
Main P.C.B.
CD Mechanism Unit
SMPS P.C.B.
Top Cabinet
Panel P.C.B.
NFC P.C.B.
USB P.C.B.
Mic P.C.B.
Front Panel Unit
CD Interface P.C.B.
