15.6. Electrical Replacement Part List
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
PRINTED CIRCUIT
BOARDS
PCB1 RFKV5318AA MAIN/NFC KIT
ASS'Y
1PN
PCB1 RFKV5318BA MAIN/NFC KIT
ASS'Y
1PS
PCB3 RFKV5318AB NFC P.C.B 1 PN
PCB3 RFKV5318BB NFC P.C.B 1 PS
PCB4 REP5316AA PANEL P.C.B 1 (RTL)
PCB5 REP5316AB MIC P.C.B 1 (RTL)
PCB6 REP5316AC USB P.C.B 1 (RTL)
PCB7 REP5304E SMPS P.C.B 1 (RTL)
PCB9 REP4945B CD INTERFACE
P.C.B
1 (RTL)
INTEGRATED CIR-
CUITS
IC52 VUEALLPT087 IC 1 (E.S.D)
IC1001 C1AB00004409 IC 1 (E.S.D)
IC1002 C0EBY0000664 IC 1 (E.S.D)
IC1003 RFKWFX5000LM IC 1 (E.S.D)
IC1004 RFKWEX9000LM IC 1 (E.S.D)
IC1201 C0DBBYY00104 IC 1 (E.S.D)
IC1202 C0ZBZ0002175 IC 1 (E.S.D)
IC1401 C1AB00003130 IC 1 (E.S.D)
IC1402 MIP2F20MSSCF IC 1 (E.S.D)
IC1501 C0DBBYY00077 IC 1 (E.S.D)
IC1601 C0DAZYY00039 IC 1 (E.S.D)
IC1701 C0DAZYY00039 IC 1 (E.S.D)
IC2001 RFKWNX9000LM IC 1 (E.S.D)
IC2101 C0DBAYY01594 IC 1 (E.S.D)
IC2102 C0ABBB000342 IC 1 (E.S.D)
IC2103 C0DBAYY01594 IC 1 (E.S.D)
IC2104 C0DBGYY03909 IC 1 (E.S.D)
IC2106 C0DBEYY00146 IC 1 (E.S.D)
IC2107 C0DBGYY00911 IC 1 (E.S.D)
IC2108 C0DBGYY03909 IC 1 (E.S.D)
IC3001 C1AB00003986 IC 1 (E.S.D)
IC3101 C1AB00004014 IC 1 (E.S.D)
IC3201 C1AB00004014 IC 1 (E.S.D)
IC3301 C1AB00003986 IC 1 (E.S.D)
IC4001 VUEALLPT090 IC 1 (E.S.D)
IC5001 C0GBY0000213 IC 1 (E.S.D)
IC6001 C0JBAZ002990 IC 1 (E.S.D)
IC6002 C0ZBZ0001747 IC 1 (E.S.D)
IC6100 C0JBAR000367 IC 1 (E.S.D)
IC9002 C0DBZYY00716 IC 1 (E.S.D)
IC9003 C0DBZYY00716 IC 1 (E.S.D)
TRANSISTORS
Q1001 B1ABCF000176 TRANSISTOR 1 (E.S.D)
Q1103 B1CERR000155 TRANSISTOR 1 (E.S.D)
Q1206 B1ABCF000176 TRANSISTOR 1 (E.S.D)
Q1402 B1ACKD000006 TRANSISTOR 1 (E.S.D)
Q1403 B3PBA0000579 TRANSISTOR 1 (E.S.D)
Q1404 B3PBA0000579 TRANSISTOR 1 (E.S.D)
Q1405 B3PBA0000579 TRANSISTOR 1 (E.S.D)
Q1501 B1CERR000147 TRANSISTOR 1 (E.S.D)
Q1502 B1CERR000147 TRANSISTOR 1 (E.S.D)
Q1505 B3PBA0000579 TRANSISTOR 1 (E.S.D)
Q1701 B3PBA0000579 TRANSISTOR 1 (E.S.D)
Q1702 B1ABCF000176 TRANSISTOR 1 (E.S.D)
Q1765 B1ADCE000012 TRANSISTOR 1 (E.S.D)
Q1766 B1ABCF000176 TRANSISTOR 1 (E.S.D)
