20.2. Electrical Replacement Parts List
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
PRINTED CIRCUIT
BOARDS
PCB1 REPX0631A iPod P.C.B. 1 (RTL)
PCB2 REPX0723A CD SERVO P.C.B. 1 (RTL)
PCB3 REPX0753A D-AMP P.C.B. 1 (RTL)
PCB4 REPX0754G MAIN P.C.B. 1 (RTL)
PCB5 REPX0755G SMPS P.C.B. 1 (RTL)
PCB6 REPX0755G TUNER P.C.B. 1 (RTL)
PCB7 REPX0755G FL P.C.B. 1 (RTL)
PCB8 REPX0754G PANEL 1 P.C.B. 1 (RTL)
PCB9 REPX0754G PANEL 2 P.C.B. 1 (RTL)
PCB10 REPX0754G AUX/HP P.C.B. 1 (RTL)
PCB11 REPX0755G IR P.C.B. 1 (RTL)
PCB12 REPX0755G MOTOR P.C.B. 1 (RTL)
PCB13 REPX0755G POSITION SW
P.C.B.
1 (RTL)
PCB14 REPX0755G iPod SW P.C.B. 1 (RTL)
PCB15 REPX0755G AC IN P.C.B. 1 (RTL)
INTEGRATED CIR-
CUITS
IC1 C1AB00003012 IC 1
IC101 C1AB00003013 IC 1
IC102 C0ABBB000230 IC 1
IC103 C0AABB000085 IC 1
IC503 C0CBCBC00090 IC 1
IC504 C0DBAYH00005 IC 1
IC505 C0DBAYH00005 IC 1
IC551 B0ADCJ000020 IC 1
IC650 C0GAE0000007 IC 1
IC701 C0DAEMZ00001 IC 1
IC702 C0DAAMH00013 IC 1
IC705 C0EBJ0000336 IC 1
IC751 MIP2F20MSSCF IC 1
IC752 C0DAEMZ00001 IC 1
IC801 RFKWMAHC3-S IC 1
IC802 C0CBCBD00008 IC 1
IC803 C0EBE0000482 IC 1
IC6801 C0HBB0000057 IC 1
IC7001 MN6627954AMA IC 1
IC7002 BA5948FPE2 IC 1
IC7003 C3ABMB000050 IC 1
TRANSISTORS
Q101 B1ABCF000176 TRANSISTOR 1
Q102 B1ABCF000176 TRANSISTOR 1
Q103 B1ABCF000176 TRANSISTOR 1
Q104 B1ABCF000176 TRANSISTOR 1
Q105 B1ABCF000176 TRANSISTOR 1
Q251 B1ABGC000005 TRANSISTOR 1
Q252 B1ABGC000005 TRANSISTOR 1
Q253 B1ABGC000005 TRANSISTOR 1
Q302 B1ABDF000026 TRANSISTOR 1
Q382 B1ADCE000012 TRANSISTOR 1
Q451 B1ABGC000005 TRANSISTOR 1
Q452 B1ABGC000005 TRANSISTOR 1
Q453 B1ABGC000005 TRANSISTOR 1
Q509 B1BAAJ000003 TRANSISTOR 1
Q511 B1ABDF000026 TRANSISTOR 1
Q512 B1ACND000003 TRANSISTOR 1
Q551 B1ACKD000006 TRANSISTOR 1
Q552 B1ABCF000176 TRANSISTOR 1
Q553 B1ABCF000176 TRANSISTOR 1
Q581 B1BABK000001 TRANSISTOR 1
Q582 B1ADCE000012 TRANSISTOR 1
Q583 B1ADCE000012 TRANSISTOR 1
Q701 B1ABEC000010 TRANSISTOR 1
Q703 B1ABCF000176 TRANSISTOR 1
Q7601 B1ADCF000001 TRANSISTOR 1
QR1 B1GBCFJJ0051 TRANSISTOR 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
